Warn Zeon 10 Bare Winch 24V (no rope/fairlead)
Regular price
£1,949.93
/
SKU: 90665
The 24V ZEON 10 bare winch has a 10,000 lb (4536kg) single-line pulling capacity.
It's planetary gear train and series-wound motor deliver fast, quiet and reliable pulling power
The convertible control pack can be attached to the winch or remotely mounted, allowing for various winch mounting options.
A control pack relocation kit required to mount the control box remotely from the winch.
| Capacity lb | 10000 |
| Capacity kg | 4536 |
| 1st layer Line Speed (no load) |
33 ft/min (10.27 m/min)
|
| Remote |
Remote with 3.7m lead.
Wireless Remote Available (90287)
|
| Clutch Operation | Manual Lever |
| Brake |
Mechanical Cone Type
|
| Fairlead (Not included) | Roller (5742) or Hawse (87914) |
| Wire Rope Spec (not included) |
3/8" (9.5 mm) x 80 ft (24.38m)
|
| Synthetic Rope Spec (not included) |
3/8" (9.5 mm) x100 ft (30.5m)
|
| Mechanical Warranty | Limited Lifetime |
| Electrical Warranty | 7 Years |
| IP Rating (winch only) | IP68 |
| Weight (kg) | 36.74 |
| Mounting Bolt Centres |
10" x 4 1/2" (254 mm 114 mm)
|
Estimated delivery - .
(Please note that some items can take longer to ship from our suppliers. We will contact you with delivery times upon receipt of your order.)
